🎮 Unreal Engine + Perforce (Helix Core) + WireGuard VPN Setup

Guide to setting up Unreal Engine collaboration with Perforce (Helix Core) over a WireGuard VPN, using an Ubuntu/Debian server and Windows clients.

A complete guide to setting up a secure collaborative workflow for Unreal Engine development using:

  1. ✅ Ubuntu/Debian Server (Perforce + WireGuard)
  2. ✅ Windows Clients (Unreal Engine + P4V)
  3. ✅ Secure LAN-like connectivity via WireGuard VPN

🔒 Security & Licensing Notice

  1. Make sure to secure your server:
    • Use strong SSH passwords or key authentication
    • Only expose necessary ports (e.g., VPN and Perforce)
    • Restrict access to VPN IPs via firewall
  2. Regularly update your system and packages to avoid vulnerabilities.
  3. ✅ Perforce (Helix Core Server) Please review the Perforce licensing terms.

🚨 Always follow best practices for securing infrastructure, especially if hosting remotely.

⚙️ 1. Setup WireGuard VPN

🖥️ On Ubuntu/Debian Server

Console Output

 sudo apt update
 sudo apt install wireguard
 wg genkey | tee privatekey | wg pubkey > publickey

Create /etc/wireguard/wg0.conf:

Console Output

 [Interface]
 Address = 10.66.66.1/24
 PrivateKey = <server-private-key>
 ListenPort = 51820
 SaveConfig = true

Enable IP forwarding:

Console Output

 echo “net.ipv4.ip_forward=1” | sudo tee -a /etc/sysctl.conf
 sudo sysctl -p

Start the VPN:

Console Output

 sudo systemctl enable wg-quick@wg0
 sudo systemctl start wg-quick@wg0

💻 On Windows Clients

Install WireGuard for Windows and use:

Console Output

 [Interface]
 PrivateKey = <client-private-key>
 Address = 10.66.66.2/32

 [Peer]
 PublicKey = <server-public-key>
 Endpoint = your.server.ip:51820
 AllowedIPs = 10.66.66.0/24
 PersistentKeepalive = 25

✅ Test: ping 10.66.66.1

📦 2. Install Perforce (Helix Core Server)

On Ubuntu/Debian Server

Console Output

 wget -qO – https://package.perforce.com/perforce.pubkey | sudo apt-key add –
 echo “deb http://package.perforce.com/apt/ubuntu jammy release” | sudo tee /etc/apt/sources.list.d/perforce.list
 sudo apt update
 sudo apt install -y helix-p4d

Create required directories:

Console Output

 sudo mkdir -p /opt/perforce/metadata /opt/perforce/depot
 sudo useradd -r -s /bin/false perforce || true
 sudo chown -R perforce: /opt/perforce

Initialize the database:

Console Output

sudo -u perforce /usr/sbin/p4d -r /opt/perforce/metadata -J journal -xi

Create systemd service:

Console Output

# /etc/systemd/system/perforce.service
[Unit]
Description=Helix Core Perforce Server
After=network.target
[Service]
User=perforce
ExecStart=/usr/sbin/p4d -r /opt/perforce/metadata -p 1666 -L /opt/perforce/metadata/log -J /opt/perforce/metadata/journal
Restart=always

Enable and start:

Console Output

 sudo systemctl daemon-reexec
 sudo systemctl enable perforce
 sudo systemctl start perforce

Install CLI (optional):

Console Output

 wget https://cdist2.perforce.com/perforce/r24.1/bin.linux26x86_64/p4
 chmod +x p4
 sudo mv p4 /usr/local/bin/

👤 3. Create User, Depot, and Workspace

On Ubuntu/Debian Server

Console Output

 p4 -p 127.0.0.1:1666 user
 p4 passwd
 p4 depot UEProject

In P4V (Windows)

  1. Workspace Name: client1_ue
  2. Root: D:UnrealProjectsMyGame
  3. View://UEProject/… //client1_ue/…

🖥️ P4V: Installing & Using the Perforce GUI

🧩 What is P4V?

P4V is the official graphical client for Perforce. It allows users to:

  1. Create and manage workspaces
  2. View changelists and depot structure
  3. Add, check out, and submit files
  4. Visualize file history and diffs

🛠️ Installing P4V on Windows

  1. Download P4V from the official Perforce website:👉 https://www.perforce.com/downloads/helix-visual-client-p4v
  2. Install and launch the client.
  3. On first launch, provide your server info:


Server

10.66.66.1:1666

Username

your Perforce user

Workspace

(leave blank initially)

⚠️ Known Issue: Large Unreal Projects May Cause Freezes

When using the “Add Files Wizard” in P4V on large Unreal projects:

  1. P4V may freeze or crash (“Not Responding”) due to scanning thousands of files
  2. Especially common if temporary folders like Binaries/, Intermediate/, or Saved/ are included

✅ Safer Alternative: Use p4 CLI for Initial Add

If P4V becomes unresponsive:

  1. Open a terminal (PowerShell or CMD)
  2. Set environment variables:

Console Output

 p4 set P4PORT=10.66.66.1:1666
 p4 set P4USER=your_username
 p4 set P4CLIENT=your_workspace

🧩 4. Unreal Engine Integration

  1. Open the .uproject inside the workspace root
  2. Go to File → Source Control → Connect to Source Control
  3. Choose Perforce and fill:


Server

10.66.66.1:1666

Username

Your Perforce user

Workspace

client1_ue

  1. Accept → green check ✅ appears
  2. Add files:
    • ✅ .uproject, Config/, Content/, Source/
    • ❌ Skip: Binaries/, Intermediate/, Saved/
  3. Submit:

Console Output

File → Submit to Source Control

Place in project root:

Console Output

 Binaries/
 DerivedDataCache/
 Intermediate/
 Saved/
 .vs/
 .vscode/
 *.sdf
 *.suo
 *.user
 *.log

Then:

Console Output

 p4 add .p4ignore
 p4 submit -d “Add ignore file”

✅ You’re Ready!

You now have:

  1. 🔒 VPN access to Perforce
  2. 🛠️ Source controlled Unreal Engine project
  3. 📡 Remote collaboration with low-latency file access

🔁 Workflow Tips



Check out file

Right-click → Check Out

Add file

Right-click → Add to Source Control

Submit changes

File → Submit to Source Control

Discard changes

Right-click → Revert

Sync latest changes

File → Sync

Made with ❤️ by Deblx for teams building games. Like this? ⭐  Follow Deblx!
